General Description

TECNEL is a Unit with Computer Control and Data Acquisition System designed to study the basis of Power Electronics. It allows students to study: AC/DC, DC/AC, DC/DC, AC/AC converters.

Basically, it consists of three modules of power electronics elements: diodes, thyristors and IGBTS.

Exercises and guided practices

GUIDED PRACTICAL EXERCISES INCLUDED IN THE MANUAL

  1. Single phase half-wave rectifier with load R.
  2. Single phase half-wave rectifier with load R-L.
  3. Single-phase half-wave rectifier with R-L load with free wheeling diode (FWD).
  4. Single-phase full-wave rectifier.
  5. Three-phase half-wave uncontrolled rectifier.
  6. Three-phase full-wave uncontrolled rectifier.
  7. Single-phase half-wave controlled rectifier.
  8. Single-phase full-wave controlled rectifier.
  9. Single-phase full-wave controlled rectifier with a DC motor.
  10. Three-phase full-wave completely controlled.
  11. Single-phase semi-controlled rectifier.
  12. Three-phase full-wave semi-controlled rectifier.
  13. Chopper.
  14. Single-phase square-wave inverter.
  15. Single-phase displaced-phase inverter.
  16. Single-phase inverter. PWM control.
  17. Three-phase inverter. PWM control with R load and R-L load.
  18. Three-phase inverter. PWM control with AC motor.
  19. Alternating regulators: R and R-L load.
  20. Asynchronous three-motor with rotor in short circuit (squirrel cage).
