10.3.- INDUSTRIAL APPLICATIONS AND SYSTEMS

An optimal operation of equipment and plants is essential in the process industry. Some devices are installed to achieve this purpose: sensors to measure the parameters to be regulated (controlled variables), actuators to allow modifying their values (manipulated variables), and controllers to define the value of the action. This set of devices is called control system.

View more

Some of the most common examples in the industry are the flow, level or temperature control systems of a fluid through pneumatic valves or solenoid valves, the pH control systems of a solution by means of dosing pumps or the systems to control the pressure and flow of a gas. However, in large industrial plants, these simple control loops do not occur in isolation, but as part of a more complex process that is controlled by a distributed control system or DCS. In these systems, simple control loops are locally regulated by industrial controllers and/or programmable logic controllers (PLCs) and monitored by a central supervisory and control system (SCADA).

The improvements in productivity and efficiency of this automation are favoring the implementation of more complex control algorithms based on the traditional PID control, such as the cascade control, feedforward control, selective control, etc. In addition, other types of algorithms are being studied, such as the predictive control, adaptive control or fuzzy control. Another important trend in these systems is related to the industrial communications field. It lies in replacing the point-to-point connections of traditional 4-20mA current loops by digital point-to-multipoint networks based on protocols and standards such as Profibus, Modbus or Ethernet.

View Products
INDUSTRIAL APPLICATIONS AND SYSTEMS UNITS
Showing 1-15 of 15 item(s)
APPLICATIONS FOR PROCESS CONTROL - APC
  • APC
Available
10.3.- INDUSTRIAL APPLICATIONS AND SYSTEMS
APC

Applications for Process Control

Today, control systems play an essential role in most industrial processes due to the significant improvements they can provide in terms of production quality, efficiency, costs and performance.The Applications for Process Control, "APC", have...
COMPUTER CONTROLLED COUPLED TANKS SYSTEM - CTAC
  • CTAC
Available
6.1.1.3.- INDUSTRIAL SYSTEM APPLICATIONS
CTAC

Computer Controlled Coupled Tanks System

The Computer Controlled Coupled Tanks System, "CTAC", consists of four transparent tanks, each with a pressure sensor to measure the water level.The coupling configuration between tanks can be modified by the use of computer controlled solenoid...
COMPUTER CONTROLLED PROCESS CONTROL UNIT (ELECTRONIC VALVE) - UCP
  • UCP
Available
6.1.1.3.- INDUSTRIAL SYSTEM APPLICATIONS
UCP

Computer Controlled Process Control Unit (Electronic Valve)

The Computer Controlled Process Control System (with electronic control valve), “UCP”, consists of a hydraulic circuit with a bottom main tank and an upper process tank, both duals. Two centrifugal pumps allow to impeller water in both tanks. Each...
COMPUTER CONTROLLED PROCESS CONTROL UNIT (PNEUMATIC VALVE) - UCPCN
  • UCPCN
Available
6.1.1.3.- INDUSTRIAL SYSTEM APPLICATIONS
UCPCN

Computer Controlled Process Control Unit (Pneumatic Valve)

The Computer Controlled Process Control System (with pneumatic control valve), “UCPCN”, consists of a hydraulic circuit with a bottom main tank and an upper process tank, both duals. Two centrifugal pumps allow to impeller water in both tanks....
COMPUTER CONTROLLED PROCESS CONTROL UNIT (SPEED CONTROLLER) - UCPCV
  • UCPCV
Available
6.1.1.3.- INDUSTRIAL SYSTEM APPLICATIONS
UCPCV

Computer Controlled Process Control Unit (Speed Controller)

The Computer Controlled Process Control System (with speed controller), “UCPCV”, consist of two dual tanks placed at different heights and two pumps that transport the water between them. The flow impelled by each pump can be adjusted using a...
COMPUTER CONTROLLED INDUSTRIAL PROCESS CONTROL PLANT - CPIC
  • CPIC
Available
6.1.1.3.- INDUSTRIAL SYSTEM APPLICATIONS
CPIC

Computer Controlled Industrial Process Control Plant

The Computer Controlled Process Control Plant with Industrial Instrumentation and Service Module (Flow, Temperature, Level and Pressure),"CPIC", is a unit, that offers, on a reasonable laboratory scale, the different process and elements that are...
