The Switching in Transmission and Distribution Substations Application, "AEL-SST-01", has been designed to study the most common operations carried out in these substations

See general description

RELATED NEWS

General Description

The Switching in Transmission and Distribution Substations Application, ,AEL-SST-01,, has been designed to study the most common operations carried out in these substations, such as, transference of the electrical service from the first busbar to the second busbar without interruptions of electrical supply, distribution through two lines in parallel, switching on/off of loads, commanding logic switch-disconnector, etc.

To demonstrate these basic principles of working, this application includes two types of busbar modules:

• Double busbar typology. These modules consist of two three-phase sets of busbars with input/output terminals to interconnect with other similar modules (feeders). Each double busbar module has two disconnectors connected each to each busbar and one circuit breaker. Through the circuit breaker, loads, generators, electrical lines, etc. will be supplied. To control the opening / closing orders of disconnectors and circuit breakers, these modules have push-buttons (local control mode) and digital signals inputs (remote control mode).

• Coupling busbar module, it consists of one coupling three-phase circuit breaker between the busbars and two three-phase disconnectors, which allows coupling the two busbars.

In addition, this application includes a network analyzer to measure voltages of different points, currents, power flows of the different feeders, etc. or a three-phase switch to interrupt the current manually or remotely.

The AEL-SST-01 has been designed to be combined with the rest of AEL-TI applications in order to form a system in which the user can learn concepts about generation, transmission, distribution and power consumption.

This application can work remotely through SCADA software AEL-TI-07/CCSOF included in the base unit AEL-TI-07. Transmission Application with Synchronous Generator.

Exercises and guided practices

GUIDED PRACTICAL EXERCISES INCLUDED IN THE MANUAL

  1. Basic wiring of double busbar substation.
  2. Double busbar coupling maneuver.
  3. Operation logic with circuit breakers and disconnectors in a double busbar substation.
  4. Load sharing with different feeders.
  5. Busbar changeover without interruption.
  6. Automatic opening of circuit breakers and disconnectors through overcurrent relay. (AEL-SST-02 base unit required).
  7. Voltage drop at the line as function of line length.
  8. Voltage drop at the line as function of the power factor of the load.
  9. Capacitive and inductive power losses on a line.
  10. Compensation of the power factor with capacitors bench.
  11. Remote coupling maneuver of double busbar with SCADA (AEL-TI-07 base unit required).
  12. Remote control operations logic with circuit breakers and disconnectors in switching substations with SCADA (AEL-TI-07 base unit required).
  13. Remote busbar changeover maneuver without interruption of supplying with SCADA (AEL-TI-07 base unit required).
  14. Voltage drop at the line as function of line length with SCADA (AEL-TI-07 base unit required).
  15. Voltage drop at the line as function of the power factor of the load with SCADA (AEL-TI-07 base unit required).
  16. Capacitive and inductive power losses on a line with SCADA (AEL-TI-07 base unit required).
  17. Load sharing with different feeders with SCADA (AEL-TI-07 base unit required).
  18. Remote control operations with circuit breakers and disconnectors with SCADA (AEL-TI-07 base unit required).
  19. Remote electrical measurements in several points of switching substation with SCADA (AEL-TI-07 base unit required).

MORE PRACTICAL EXERCISES TO BE DONE WITH THE UNIT

  1. Many students view results simultaneously. To view all results in real time in the classroom it can be used a projector or an electronic whiteboard.
  2. The Computer Control System with AEL-TI-07/CCSOF allows a real industrial simulation.
  3. This application is totally safe as uses mechanical, electric and electronic, and software safety devices.
  4. This application can be used for doing applied researc.
  5. This application can be used for giving learning courses to industries even to other Technical Education Institutions.

- Several other exercises can be done and designed by the user.
