ESED 沈殿学習装置

11.1.11.- ろ過、沈降および混合 13.1.- 水文地質学と水文地質学

Unit: ESED. Sedimentation Study Unit

革新的なシステム

The Sedimentation Study Unit, "ESED", allows studying and compare the sedimentation processes of several suspensions simultaneously.

一般的な説明を表示

カタログ

コンテストの仕様

拡張

ICAI

対話型コンピューター支援命令ソフトウェア

研究室

化学工学研究室

高等教育化学工学研究室

石油研修センター研究室

技術教育・職業教育環境実験室

高等教育環境研究室

Setting up at Faculté des Sciences at the Université d’Etat d’Haiti

We want to present our new installation in the Faculté des Sciences at the Université d’Etat d’Haiti, specifically in the Fluid Mechanics Department. There, we have installed many of our equipment, among which are: AFT, CF80/5 (with CFAS, CFFS, CFPLR, CFPR, CFRM, CFSDL, CFTP, CFTS, CFVD, CFVEN,...

03 May 2021, 11:40 続きを読む

NEW Environmental leaflets

Due to the growing awareness of environmental problems, not only individuals but also governments and companies have started to develop activities that tend to preserve or limit the damage to the environment. Thus, some disciplines of the environmental science, such as hydrology, hydrogeology,...

29 May 2018, 12:13 続きを読む

概要

The Sedimentation Study Unit, "ESED", allows studying and compare the sedimentation processes of several suspensions simultaneously.

It is formed by five sedimentation methacrylate cylinders mounted vertically on a panel, incorporating measuring scales appropriate lighted for easing observation.

All that, enables the simultaneous study of the behaviour of five different suspensions.

Each cylinder may be removed from the panel for the appropriate washing and conditioning.

The unit is supplied with: stopwatch, light diffuser screen, fluorescent tubes, beakers, graduated cylinder and pycnometer.

It enables to have available several amounts in suspension, in order to study the differences in the sedimentation regimens, measuring the changes in heights of the solid-liquid interfaces respect to time.

演習と指導の慣行

マニュアルに含まれるガイド付き実習

Variation of the sedimentation characteristics with the concentration and suspension height.
Effect of initial concentration on sedimentation characteristics.
Effect of initial suspension height on sedimentation characteristics.
Construction of settling rate curves against concentration form a single batch test.
Effect of particle size distribution.
Identification of the different sedimentation regimes.
Use of flocculating additives.
Construction of settling rate curves.
Visualization of the retarded sedimentation.
Study of the differences between a clarifier and a classifier.
Study and visualization of the differential sedimentation.
Study of the methods of sinking and floating.
