10.3.- INDUSTRIELLE ANWENDUNGEN UND SYSTEME

Ein optimaler Betrieb der Ausrüstung und Anlagen ist in der Prozessindustrie unerlässlich. Einige Geräte werden installiert, um diesen Zweck zu erreichen: Sensoren zur Messung der zu regelnden Parameter (Regelgrössen), Aktoren zur Änderung ihrer Werte (Manipulierte Variablen) und Regler zur Festlegung des Wertes der Aktion. Dieser Satz von Vorrichtungen heißt Steuerungssystem.

Mehr sehen

Einige der gängigsten Beispiele in der Industrie sind Fluss, Niveau oder TemperaturSteuersysteme eines Fluids durch Pneumatikventile oder Magnetventile, die pH-Regelsysteme einer Lösung mittels Dosierung Pumpen oder die Systeme zur Regelung des Drucks und Durchflusses eines Gases. In großen Industrieanlagen treten diese einfachen Regelkreise jedoch nicht isoliert auf, sondern als Teil eines komplexeren Prozesses, der durch ein verteiltes Regelsystem oder DCS gesteuert wird. In diesen Systemen werden einfache Regelkreise lokal durch Industrieregler und/oder Programmierbare Logikcontroller (SPSen) geregelt und durch ein zentrales Überwachungs- und RegelsystemSystem (SCADA) überwacht.

Die Produktivitäts- und Effizienzverbesserungen dieser Automatisierung begünstigen die Implementierung komplexerer Regelalgorithmen basierend auf der traditionellen PID-Regelung, wie z.B. der Kaskadenregelung,Feedforward-Regelung, selektiven Regelung, etc. Darüber hinaus werden auch andere Arten von Algorithmen untersucht, wie z.B. die Prädiktive Regelung, adaptive Regelung oder Fuzzy-Regelung. Ein weiterer wichtiger Trend in diesen Systemen steht im Zusammenhang mit dem Bereich industrielle Kommunikation. Er besteht darin, die Punkt-zu-Punkt-Verbindungen der traditionellen 4-20mA-Stromschleifen durch digitale Punkt-zu-Multipunkt-Netzwerke zu ersetzen, die auf Protokollen und Standards basieren, wie z.B. Profibus, Modbus oder Ethernet.

Siehe Produkte
INDUSTRIELLE ANWENDUNGEN UND SYSTEME UNITS
1 - 13 von 13 Artikel(n)
APPLICATIONS FOR PROCESS CONTROL - APC
  • APC
Available
10.3.- INDUSTRIELLE ANWENDUNGEN UND SYSTEME
APC
Applications for Process Control
The Applications for Process Control, "APC", designed by EDIBON, allows the student to design, assemble and configure various control systems, apart from studying the fundamentals of the control engineering on which they are based.These...
COMPUTER CONTROLLED COUPLED TANKS SYSTEM - CTAC
  • CTAC
Available
6.1.1.3.- INDUSTRIELLE SYSTEMANWENDUNGEN
CTAC
System aus gekoppelten Tanks, computergesteuert.
The Computer Controlled Coupled Tanks System, "CTAC", consists of four transparent tanks, each with a pressure sensor to measure the water level.The coupling configuration between tanks can be modified by the use of computer controlled solenoid...
COMPUTER CONTROLLED PROCESS CONTROL (PNEUMATIC VALVE) - UCPCN
  • UCPCN
Available
6.1.1.3.- INDUSTRIELLE SYSTEMANWENDUNGEN
UCPCN
Computergesteuerte Prozesseinheit (Pneumatikventil)
The Computer Controlled Process Control (Pneumatic Valve), "UCPCN", designed by EDIBON, allows the study of several types of automatic control and can be used to control different variables (flow, level, temperature, pressure, pH, conductivity and...
COMPUTER CONTROLLED PROCESS CONTROL (SPEED CONTROLLER) - UCPCV
  • UCPCV
Available
6.1.1.3.- INDUSTRIELLE SYSTEMANWENDUNGEN
UCPCV
Computergesteuerte Prozesssteuerung (Drehzahlregler)
The Computer Controlled Process Control Unit (Speed Controller), "UCPCV", designed by EDIBON, allows the study of several types of automatic control and can be used to control different variables (flow, level, temperature, pressure, pH,...
COMPUTER CONTROLLED INDUSTRIAL PROCESS CONTROL PLANT - CPIC
  • CPIC
Available
6.1.1.3.- INDUSTRIELLE SYSTEMANWENDUNGEN
CPIC
Industrielles Prozessleitsystem, Computergesteuert (PC)
The Computer Controlled Process Control Plant with Industrial Instrumentation and Service Module (Flow, Temperature, Level and Pressure),"CPIC", is a unit, that offers, on a reasonable laboratory scale, the different process and elements that are...
