AE-PLC-T Estação de Transporte Linear

LINEAR TRANSPORT WORKSTATION - AE-PLC-T

SISTEMAS INOVADORES

The "AE-PLC-T" is a linear transporting system, which moves the pallets, that carries the pieces, along the system.

Ver descrição geral

Descrição Geral

The "AE-PLC-T" is a linear transporting system, which moves the pallets, that carries the pieces, along the system. The unit is configured in a closed loop conveyor powered by an electrical motor, the whole system is commanded by a PLC.

The "AE-PLC-T" has different stopping places, where the system detects the pallet and is able to stop the transporting system.

The "AE-PLC-T" workstation is designed as a modular system to facilitate the understanding of the unit. The main components are:

  • The PLC: is composed by the CPU PLC unit and all the extra modules needed to perform a correct working of the workstation.
  • The control panel: with start/stop button, emergency pushbutton, reset button, light indicators to show current state of the process, etc.
  • The pneumatic circuit: contains the required solenoid valves, pressure components, pneumatic actuators, filters and regulators to assure the appropriate working of the unit.
  • The workstation: is composed by real industrial components used by the industrial transporting systems, such as inductive sensors, presence sensors, motor controllers, etc.

The "AE-PLC-T" is an independent workstation that can work alone and/or in conjunction with other workstations to make up a complete Flexible Manufacturing system*.

*The Flexible manufacturing systems product list is available at "Flexible Manufacturing Systems (FMS)" area of the general catalogue.

EXERCÍCIOS E PRÁTICAS GUIADAS

EXERCÍCIOS PRÁTICOS GUIADOS INCLUÍDOS NO MANUAL

  1. Introduction to flexible manufacturing system (FMS).
  2. Introduction to pneumatics and electro-pneumatics.
  3. Study of the sensor detection.
  4. Configuration of a pneumatic application.
  5. Manual control of a transporting system.
  6. Automatic control of a transporting system.
  7. Change the parameters of a transporting process.
  8. Optimize the process time.
  9. Study and analysis of the faults inserted in the process with the fault generation module.
