AEL-FCLL Применение топливных элементов для производства энергии

FUEL CELL ENERGY APPLICATION - AEL-FCLL

ИННОВАЦИОННЫЕ СИСТЕМЫ

ОБЩЕЕ ОПИСАНИЕ

The Fuel Cell Energy Application, "AEL-FCLL", has been designed by EDIBON to demonstrate how fuel cells work.

This application includes a proton exchange membrane (PEM) fuel cell stack composed of several cells in the shape of a ribbed plate that allow air flow across the membrane. The membrane facilitates the flow of hydrogen, generating the release of electrons. There are separate plates that conduct electricity, allowing the flow of electrons, between each pair of cells. In addition, protection systems, electronic charging and solenoid valve are included. EDIBON offers the possibility of including an electrolyzer so as not to depend on a hydrogen cylinder.

УПРАЖНЕНИЯ И ПРИМЕРЫ С ИНСТРУКЦИЯМИ

РУКОВОДСТВО ПО ПРАКТИЧЕСКИМ УПРАЖНЕНИЯМ ВКЛЮЧЕНО В РУКОВОДСТВО ПОЛЬЗОВАТЕЛЯ

  1. Basic fuel cell operations.
  2. Design and operation of a metal hydride storage cell.
  3. Calculation of the efficiency of a PEM fuel cell.
  4. Study of the influence of the air consumption and the hydrogen consumption on the efficiency of a PEM fuel cell.
  5. Study of the energy density of a PEM fuel cell.
  6. Representation of the polarisation curve of a PEM fuel cell.
  7. Determination of the voltage and current density characteristics of a PEM fuel cell.
  8. Study of the influence of hydrogen consumption in the generation of electrical energy.
  9. Study of the influence of the power generated on the efficiency of a PEM fuel cell.
  10. Study of the influence of the flow of reagents in the generation of electricity.
  11. Study of voltage conversion.

БОЛЬШЕ ПРАКТИЧЕСКИХ УПРАЖНЕНИЙ ДЛЯ РАБОТЫ С УСТРОЙСТВОМ

Additional practical exercises with the electrolyser:

  1. Study of electrolyser.
  2. Study the standalone power supply.

Additional practical exercises:

  1. Several other exercises can be done and designed by the user.
